| Max Tire | 27.5"x2.4" or 26"x2.4" |
| Steerer | 1.5" Aluminum tapered 28.6mm Aluminum |
| Lower | 20*110mm QR Axle (Boost) |
| Travel | 160, 170, 180mm |
| MODEL | 27.5 / 26 AIR | 27.5 / 26 COIL |
| Max Tire | 27.5"x2.4" or 26"x2.4" | |
| Spring | Air3 | Coil |
| Damper | OCRC+ Compress adjust Rebound adjust |
|
| Lock-Out Remote | - | |
| Steerer | 1.5" Aluminum tapered 28.6mm Aluminum | |
| Crown | 138mm | |
| Stanchion | 36mm Aluminum Hard Anodize Black |
|
| Lower | Magnesium 20*110mm QR Axle (Non-Boost) |
|
| Lamp Mount | - | |
| Fender Mount | mudguard | |
| Travel | 160, 170, 180mm | |
| Fork Offset | 43mm | |
| Fork Height | 27.5":555/565/575mm 26":540/550/560mm |
|
| Brake Type | Post-Mount Disc (180 - 220mm max.) |
|
