| Max Tire | 27.5"x2.4" / 26"x2.4" |
| Steerer | 28.6mm Aluminum / 1.5" to 1.125" Aluminum tapered |
| Lower | 15*100mm QR Axle |
| Travel | 80,100,130 mm |
| MODEL | HC |
| Max Tire | 27.5"x2.4" or 26"x2.4" |
| Spring | Air |
| Damper | OCR2+ Compress adjust Rebound adjust |
| Lock-Out Remote | - |
| Steerer | 1.5" to 1.125" Aluminum tapered 28.6mm Aluminum |
| Crown | 130mm |
| Stanchion | 34mm Aluminum Hard Anodize Black |
| Lower | Magnesium 15*100mm QR Axle |
| Lamp Mount | - |
| Travel | 80, 100, 130mm |
| Fork Offset | 43mm |
| Fork Height | 27.5": 475, 495, 525mm 26": 470, 490, 520mm |
| Brake Type | Post-Mount Disc (180 - 220mm max.) |
| Weight | 2.15kg |
