| Max Tire | 26"x2.4" /24"x2.6"/20"x2.4" |
| Steerer | 28.6mm Aluminum / 1.5" to 1.125" Aluminum tapered |
| Lower | 15*100mm Bolt Axle/ 9*100mm Open Dropout |
| Travel | 60,80,100,120 mm |
| MODEL | 26 AIR | 26 AIR-TRL | 24 AIR | 24 AIR-TRL | 20 AIR | 20 AIR-TRL |
| Max Tire | 26"x2.4" | 26"x2.4" | 24"x2.6" | 24"x2.6" | 20"x2.4" | 20"x2.4" |
| Spring | Air | |||||
| Damper | BO-TNL Compress adjust Rebound adjust Lock-Out | BO-TNL Compress adjust Rebound adjust | BO-TNL Compress adjust Rebound adjust Lock-Out | BO-TNL Rebound adjust Lock-Out | BO-TNL Compress adjust Rebound adjust Lock-Out | BO-TNL Rebound adjust Lock-Out |
| Lock-Out Remote | - | V | - | V | - | V |
| Steerer | 1.5" Aluminum tapered 28.6mm Aluminum |
|||||
| Crown | 130mm | 130mm | 130mm | 130mm | 130mm | 130mm |
| Stanchion | 32mm Aluminum Hard Anodize Black |
|||||
| Lower | Magnesium 15*100mm Bolt Axle 9*100mm Open Dropout |
|||||
| Lamp Mount | - | - | - | - | - | - |
| Fender Mount | mudguard/long fender | |||||
| Travel | 60, 80, 100, 120mm | 60, 80, 100mm | ||||
| Fork Offset | 38mm | |||||
| Fork Height | 440, 460, 480, 500mm | 419, 439, 459, 479mm | 370,390.410mm | |||
| Brake Type | Post-Mount Disc (160 - 180mm max.) |
|||||
