| Max Tire | 27.5"x2.4" / 26"x2.4" |
| Steerer | 28.6mm Aluminum |
| Lower | 20*110mm Boost Bolt Axle |
| Travel | 200 mm |
| MODEL | 27.5 RL | 27.5 TNL | 27.5 MLC | 27.5 T |
| Max Tire | 27.5″x2.2″ & 26″x2.4″ | |||
| Spring | Coil (Preload Adjust) | |||
| Damper | TNL Lock-Out | TNL Lock-Out | MLC Mechanic-Lock-Out | – |
| Lock-Out Remote | V | – | – | – |
| Steerer | 1.5″ to 1.125″ Steel tapered 28.6mm Steel |
|||
| Crown | 130mm | |||
| Stanchion | 30mm Steel CP Finish |
|||
| Lower | Aluminum 15*100mm Bolt Axle 9*100mm Open Dropout * for Front Hub Drive |
|||
| Lamp Mount | PLS | |||
| Travel | 50, 60, 80mm | |||
| Fork Offset | 44mm | |||
| Fork Height | 440, 450, 470mm | |||
| Brake Type | Post-Mount Disc (160 – 180mm max.) |
|||
| Weight | 2.95kg | 2.89kg | 2.66kg | 2.66kg |
